TSC MX241P 4-inch Industrial Barcode Printer (203/300 dpi)

Product Specifications

---

Feature	Detail
Brand	TSC
Model	MX241P Industrial Barcode Printer (203/300 dpi)
Print Resolution	203 DPI (8 dots/mm) & 300 DPI (12 dots/mm) switchable
Print Width	4.1 inches (104 mm) maximum
Print Speed	Up to 10 ips (254 mm/sec) at 203 dpi, 6 ips (152 mm/sec) at 300 dpi
Print Method	Direct Thermal & Thermal Transfer
Memory	64MB Flash, 32MB SDRAM
Connectivity	USB 2.0, Serial RS-232, Ethernet 10/100, Parallel, Optional Wi-Fi
Supported 1D Barcodes	Code 128, Code 39, Code 93, EAN-13, EAN-8, UPC-A, UPC-E, Interleaved 2 of 5, Codabar, MSI, ITF-14, GS1-128
Supported 2D Barcodes	QR Code, DataMatrix, PDF417, Aztec, MaxiCode, MicroPDF417
Media Compatibility	Label widths: 1.0" to 4.5", Max roll diameter: 5 inches (127 mm)
Dimensions (W×D×H)	11.8" × 14.9" × 12.6" (300 × 378 × 320 mm)
Weight	Approximately 17.6 lbs (8 kg)
Operating Temperature	41°F to 104°F (5°C to 40°C)
Power Supply	Input: 100-240V AC, 50-60Hz, Output: 24V DC, 4.2A
Printhead Life	100 km (under normal operating conditions)

Product Details

---

The TSC MX241P Industrial Barcode Printer represents the perfect balance between speed and quality with its innovative dual-resolution capability. This unique feature allows businesses to switch between 203 dpi for high-speed printing of standard labels and 300 dpi for high-quality printing of detailed graphics, small text, or high-density barcodes. This flexibility makes the MX241P an ideal solution for diverse labeling requirements within a single organization.

Engineered for maximum versatility, the MX241P supports both direct thermal and thermal transfer printing methods, providing the freedom to choose the most suitable technology for specific applications. Whether printing shipping labels that require speed or product labels that demand high-resolution graphics, this printer adapts to deliver optimal results for each scenario.

The printer's comprehensive connectivity suite including USB, Ethernet, Serial, and optional Wi-Fi ensures seamless integration into existing IT infrastructures. This connectivity flexibility supports efficient operation in diverse environments such as warehouse management systems, manufacturing facilities, retail operations, and distribution centers where different departments may have varying resolution requirements.

With its robust industrial-grade construction, the MX241P is built to withstand demanding operational conditions. The printer features sufficient memory to handle complex label designs and batch printing operations efficiently, ensuring consistent performance during high-volume printing sessions. The ability to switch resolutions on-demand provides cost-effective flexibility without the need for multiple printers.

The MX241P is particularly valuable for organizations with mixed labeling needs such as logistics companies that require both fast shipping labels and detailed product labels, or manufacturing facilities that need both basic identification labels and high-quality compliance labels. Backed by TSC's reputation for reliability and supported by Markaa's comprehensive service network, the MX241P ensures long-term operational efficiency and adaptability for evolving business requirements.
