TSC TTP-384MT 4-Inch Mobile Barcode Printer - Industrial Wide Format Handheld Thermal Transfer

Key Features

---

Model Comparison: TTP-384MT vs TTP-286MT

---

Product Specifications

---

Feature	Detail
Brand	TSC Auto ID
Model	TTP-384MT Mobile Barcode Printer
Printer Type	Handheld Mobile Thermal Transfer Printer
Print Resolution	203 DPI (8 dots/mm)
Maximum Print Width	4.1 inches (104 mm)
Print Speed	Up to 4 ips (102 mm/sec)
Print Method	Thermal Transfer Only
Connectivity	Bluetooth 4.2+, USB 2.0 (cable connection)
Wireless Range	Up to 15 meters (49 feet) line of sight
Battery Type	Rechargeable Lithium-ion 7.4V, 5200mAh
Battery Life	Up to 10 hours continuous printing
Charging Time	Approximately 4 hours (0-100%)
Durability Rating	IP54 (Dust and water splash resistant)
Drop Specification	1.5 meter (5 feet) drop resistant
Operating Temperature	23°F to 104°F (-5°C to 40°C)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Supported Barcode Types	Code 128, Code 39, Code 93, EAN-13, EAN-8, UPC-A, UPC-E, Interleaved 2 of 5, Codabar, QR Code, DataMatrix, PDF417, MaxiCode
Media Compatibility	Label widths: 1.0" to 4.2" (25 to 107 mm), Max roll diameter: 3.1" (79 mm)
Label Thickness Range	0.002" to 0.008" (0.05 to 0.20 mm)
Physical Dimensions	10.2" × 6.3" × 3.5" (259 × 160 × 89 mm)
Unit Weight	Approximately 2.9 lbs (1.3 kg) with battery
Display	Enhanced backlit LCD with graphical interface
Software Compatibility	iOS, Android, Windows compatible with enterprise integration
Memory	16MB Flash, 8MB SDRAM
Ribbon Compatibility	Wax, Wax-Resin, Resin ribbons (Up to 300 meters)
Printhead Life	50 km (under normal operating conditions)
Warranty	1-year limited warranty

Product Details

---

The TSC TTP-384MT represents a significant advancement in mobile labeling technology, specifically designed to address the growing need for wide-format mobile printing capabilities in industrial and logistics applications. With its impressive 4.1-inch print width, this handheld printer delivers labeling capabilities previously only available from stationary desktop printers, enabling on-site printing of shipping labels, compliance documentation, large asset tags, and comprehensive product labels directly at the point of application. This wide-format mobile capability eliminates the need to transport items to fixed printer locations, dramatically improving workflow efficiency and operational flexibility.

Engineered for durability in demanding industrial environments, the TTP-384MT features robust construction with enhanced protection against environmental challenges. The IP54-rated enclosure provides reliable operation in warehouse conditions, manufacturing environments, outdoor applications, and field service operations where dust, moisture, and physical impacts are common. The reinforced casing and shock-resistant design ensure continued performance in conditions that would compromise conventional mobile printers, providing labeling capability where it's needed most, regardless of environmental challenges.

The thermal transfer printing technology employed by the TTP-384MT delivers exceptional advantages for mobile labeling applications requiring label durability. Unlike direct thermal printing, thermal transfer creates permanent, long-lasting labels using ribbons, resulting in printed images that withstand fading, abrasion, moisture, chemicals, UV exposure, and extreme temperatures. This durability is particularly valuable for applications where labels must maintain readability in harsh conditions, including outdoor asset tracking, warehouse rack labeling, industrial component identification, shipping documentation, and field service records.

This wide-format mobile printer excels in these specific industrial applications:

• Warehouse & Logistics Operations: On-site printing of shipping labels, bill of lading documents, pallet identification tags, and freight labels directly at loading docks and distribution points without returning to fixed workstations.
• Field Service & Maintenance: Large format equipment labeling, comprehensive service documentation, compliance labeling, and maintenance records during field service visits and on-site maintenance operations.
• Manufacturing & Production: Work-in-progress labeling, quality control documentation, assembly instructions, and production tracking labels directly on the manufacturing floor for larger components and products.
• Retail & Store Operations: Wide format price labels, promotional signage, shelf-edge labeling, and comprehensive product information directly on the sales floor for larger retail items and displays.
• Construction & Facilities Management: Large asset identification tags, equipment labeling, safety compliance signage, and maintenance tracking for construction sites and facility management operations.
• Healthcare & Laboratory: Comprehensive specimen labeling, patient identification documents, medication tracking, and equipment documentation requiring wider label formats in healthcare facilities.
• Transportation & Fleet Management: Vehicle identification labels, comprehensive maintenance records, compliance documentation, and load identification for transportation and fleet operations.
• Government & Compliance: Regulatory compliance labels, inspection documentation, safety certifications, and official documentation requiring wide format mobile printing capabilities.

Bluetooth 4.2+ connectivity provides robust wireless integration with mobile devices, tablets, and enterprise systems, enabling flexible printing from various sources. The enhanced wireless capability supports extended range and improved connection stability, allowing operators to move freely within larger work areas while maintaining reliable printing capability. Support for multiple connection protocols and enterprise integration ensures compatibility with various operational systems, mobile applications, and labeling software platforms, providing flexibility in implementation and use.

The high-capacity 5200mAh rechargeable lithium-ion battery provides extended operational capability, supporting up to 10 hours of continuous printing on a single charge. Intelligent power management optimizes battery usage based on operational patterns, while fast-charging capability minimizes downtime between shifts. The battery system is designed for easy replacement and maintenance, ensuring continued productivity throughout extended work cycles and multiple operational periods.

Enhanced ergonomic design considerations ensure comfortable operation during extended use with the wider printer format. The balanced weight distribution, integrated carry handle, and optimized control layout reduce operator fatigue and improve handling efficiency with the larger device. The enhanced backlit LCD display provides comprehensive status information, operational feedback, and graphical interface elements, while tactile controls enable easy operation even when wearing industrial gloves or in variable lighting conditions.

Media handling capabilities are specifically optimized for wide-format mobile operation, with intuitive loading mechanisms that simplify media changes in field conditions. The printer accommodates 3.1-inch diameter label rolls, providing increased capacity for typical wide-format mobile labeling applications while maintaining reasonable dimensions for handheld operation. Support for various label materials and ribbon types enables flexibility in meeting specific application requirements for label durability, adhesion, and environmental resistance.

Software compatibility extends across major platforms, with dedicated mobile applications for iOS and Android devices providing sophisticated label design and printing capabilities. Enterprise integration options support connection to existing labeling systems, databases, and operational software, enabling real-time data retrieval and dynamic label generation based on specific operational requirements. The enhanced memory configuration supports storage of complex label formats, graphics, and frequently used templates, reducing setup time and improving operational efficiency.

Maintenance and serviceability are designed with industrial field operation in mind. Modular components, easy-access service points, and comprehensive diagnostic capabilities simplify routine maintenance and troubleshooting in field conditions. The industrial-grade printhead design provides reliable performance in challenging conditions, with expected service intervals aligned with demanding industrial usage patterns.

Backed by TSC's industrial expertise and supported by Markaa's comprehensive service network throughout India, the TTP-384MT represents a strategic investment for businesses seeking to enhance mobility in their wide-format labeling operations. Whether implementing new mobile labeling solutions or extending existing systems to field operations requiring larger label formats, this printer delivers the durability, performance, and flexibility needed to meet demanding industrial mobile labeling requirements while providing excellent return on investment through improved operational efficiency, workflow optimization, and enhanced labeling capabilities.
