TSC TL-240 Desktop Barcode Printer
TSC TL-240 Desktop Barcode Printer
Desktop Barcode PrinterThe TSC TL-240 is a compact and reliable desktop barcode printer designed for small to medium businesses. With its user-friendly design and efficient performance, it's perfect for retail, office, and light industrial applications where space is limited but quality printing is essential.
Key Features of the TSC TL-240 Barcode Printer:
- Resolution : 203 DPI (8 dots/mm)
- Max. Print Width : 104 mm (4.1 inches)
- Maximum Print Speed : 127 mm/second (5 inches/second)
- Print Method : Direct Thermal
- Label Width : 1.2" to 4.25" (30 mm to 108 mm)
- Connectivity : USB 2.0, Serial, Parallel
- Compact Design : Space-saving footprint
- Easy Media Loading : Front-loading design
Product Specifications
| Feature | Detail |
|---|---|
| Brand | TSC |
| Model | TL-240 Desktop Barcode Printer |
| Print Technology | Direct Thermal |
| Resolution | 203 DPI (8 dots/mm) |
| Maximum Print Speed | 127 mm/second (5 inches/second) |
| Maximum Print Width | 104 mm (4.1 inches) |
| Label Width Range | 30 mm to 108 mm (1.2" to 4.25") |
| Media Thickness | 0.06 mm to 0.19 mm |
| Media Roll Diameter | Max 127 mm (5 inches) |
| Core Size | 25.4 mm (1 inch) or 38 mm (1.5 inches) |
| Memory | 8 MB Flash, 8 MB SDRAM |
| Connectivity | USB 2.0, Serial RS-232, Parallel IEEE-1284 |
| Supported Barcodes | Code 128, Code 39, Code 93, EAN-13, EAN-8, UPC-A, UPC-E, Interleaved 2 of 5, Codabar, PDF417, QR Code, Data Matrix |
| Dimensions (W x D x H) | 268 mm x 258 mm x 178 mm |
| Weight | 2.8 kg |
| Operating Temperature | 5°C to 40°C (41°F to 104°F) |
| Operating Humidity | 20% to 85% RH (non-condensing) |
Product Details
The TSC TL-240 Desktop Barcode Printer is an efficient and compact thermal printing solution designed for businesses that require reliable label printing in limited spaces. This printer combines ease of use with professional performance, making it ideal for retail environments, small warehouses, offices, and light industrial applications.
With a maximum print speed of 127 mm per second and 203 DPI resolution, the TL-240 delivers crisp, clear barcodes, text, and graphics on various direct thermal labels. Its front-loading media design simplifies label loading and replacement, minimizing downtime and improving workflow efficiency.
The TL-240 supports a wide range of barcode symbologies including 1D codes like Code 128, UPC, and EAN, as well as 2D codes such as QR Code and Data Matrix. This versatility allows businesses to print labels for product identification, shipping, inventory management, and compliance labeling.
Multiple connectivity options including USB, serial, and parallel ports ensure compatibility with various computer systems and point-of-sale setups. The compact footprint (268mm x 258mm x 178mm) makes it easy to integrate into existing workstations without requiring significant desk space.
Built with durability in mind, the TL-240 features a robust metal frame that withstands daily use in busy environments. Its simple operation and minimal maintenance requirements make it an excellent choice for businesses seeking an affordable, reliable barcode printing solution that doesn't compromise on quality or performance.
TSC TL-240 Desktop Barcode Printer Brochure
TSC TL-240: Loading Media & Ribbon
Learn how to load media and ribbon in your TSC TL-240 desktop barcode printer for optimal performance.
TSC DL Series: Loading the Media
Watch how to properly load media in TSC DL series desktop barcode printers.
Industries & Applications
