TSC PEX-2240L 2-inch Desktop Barcode Printer (203 dpi)
TSC PEX-2240L 2-inch Desktop Barcode Printer (203 dpi)
Compact Desktop Label PrinterThe TSC PEX-2240L is a compact and affordable 2-inch desktop barcode printer designed for small businesses, retail stores, and office environments. With its space-saving design and reliable 203 dpi printing capability, this printer delivers professional-quality labels for various applications including product labeling, shipping labels, asset tags, and more. Perfect for users who need a reliable labeling solution without the complexity of industrial printers.
Key Features of the TSC PEX-2240L Desktop Printer:
- Compact Design: Space-saving footprint ideal for desktop use
- Print Width: 2.1 inches (54 mm) maximum for standard label applications
- Print Resolution: 203 DPI for clear, readable barcodes and text
- Print Speed: Up to 4 inches per second (102 mm/sec)
- Print Method: Direct thermal printing (no ribbons required)
- Memory: 8MB Flash, 4MB SDRAM for label storage
- Connectivity: USB 2.0 for easy plug-and-play operation
- Media Handling: Supports 0.7" to 2.2" label widths, 3.1" roll diameter
- User-Friendly: Simple operation with minimal setup required
- Cost-Effective: Affordable pricing with low operating costs
Product Specifications
| Feature | Detail |
|---|---|
| Brand | TSC |
| Model | PEX-2240L Desktop Barcode Printer (203 dpi) |
| Printer Type | Desktop Thermal Barcode Printer |
| Print Resolution | 203 DPI (8 dots/mm) |
| Print Width | 2.1 inches (54 mm) maximum |
| Print Speed | Up to 4 ips (102 mm/sec) |
| Print Method | Direct Thermal Only |
| Memory | 8MB Flash, 4MB SDRAM |
| Connectivity | USB 2.0 (Standard), Optional Ethernet |
| Supported 1D Barcodes | Code 128, Code 39, Code 93, EAN-13, EAN-8, UPC-A, UPC-E, Interleaved 2 of 5, Codabar, MSI |
| Supported 2D Barcodes | QR Code, DataMatrix, PDF417 |
| Media Compatibility | Label widths: 0.7" to 2.2" (18 to 56 mm), Max roll diameter: 3.1" (79 mm) |
| Label Thickness | 0.002" to 0.006" (0.05 to 0.15 mm) |
| Dimensions (W×D×H) | 7.1" × 9.8" × 7.5" (180 × 250 × 190 mm) |
| Weight | Approximately 5.5 lbs (2.5 kg) |
| Operating Temperature | 41°F to 95°F (5°C to 35°C) |
| Power Supply | Input: 100-240V AC, 50-60Hz, Output: 24V DC, 2.5A |
| Printhead Life | 50 km (under normal operating conditions) |
| Noise Level | Less than 55 dB during operation |
Product Details
The TSC PEX-2240L Desktop Barcode Printer offers an ideal entry-level solution for businesses and individuals who require professional-quality label printing in a compact, easy-to-use format. Designed specifically for desktop environments, this printer combines simplicity with functionality, making it perfect for small retail shops, offices, warehouses, libraries, healthcare facilities, and educational institutions.
As a direct thermal printer, the PEX-2240L eliminates the need for ribbons, toner, or ink cartridges, significantly reducing operational costs and maintenance requirements. This makes it particularly suitable for applications where printing volume is moderate and cost-efficiency is important. The printer uses specially coated thermal paper that darkens when heated by the printhead, producing crisp, clear labels with excellent scannability.
The compact footprint of the PEX-2240L allows it to fit comfortably on any desk, counter, or workspace without consuming valuable real estate. Despite its small size, the printer delivers reliable performance with a print speed of up to 4 inches per second, sufficient for most small to medium-volume labeling tasks. The 203 dpi resolution ensures that barcodes are sharp and easily scannable, while text and graphics remain clear and legible.
Setup and operation of the PEX-2240L are remarkably straightforward. The USB connectivity enables plug-and-play installation with most computers and operating systems, while the intuitive design makes media loading simple and hassle-free. The printer supports standard 2-inch label widths, which are commonly used for product labeling, shipping labels, inventory tags, and asset management labels.
Typical applications for the PEX-2240L include:
- Retail: Price tags, product labels, shelf labels
- Office: File folder labels, asset tags, mailing labels
- Shipping: Small package labels, address labels
- Healthcare: Specimen labels, medication labels
- Library: Book spine labels, inventory labels
- Education: Equipment labels, storage labels
- Small Business: Product identification, inventory control
The printer's energy-efficient design and quiet operation make it suitable for office environments where noise levels and power consumption are considerations. The included TSC printer drivers and label design software compatibility ensure seamless integration with existing systems and workflows.
Maintenance requirements for the PEX-2240L are minimal, with the primary consumable being the thermal labels themselves. The printhead has an expected lifespan of approximately 50 kilometers, providing long-term reliability for typical usage scenarios. The simple mechanical design reduces the likelihood of breakdowns and makes any necessary servicing straightforward.
Backed by TSC's reputation for quality and supported by Markaa's comprehensive service network, the PEX-2240L represents an excellent value proposition for users seeking a reliable, cost-effective labeling solution. Whether you're a small business owner, office administrator, retail manager, or individual user, this printer provides the functionality you need without unnecessary complexity or expense.
